| PACKAGING MACHINES |
|
|
|
 |
| Semi-Automatic OPP Sealer Top and Bottom Belts Driven |
| Model: |
SJ-551TB |
| Carton Size: |
150 - ∞ (L) 160 - 500 (W)
100-500 (H) mm |
| Working Speed: |
700-1200 Carton/hrs |
| Tape Width: |
48mm, 72mm |
|
|
| |
| |
 |
| Semi-Automatic OPP Sealer Side and Top Belts Driven |
| Model: |
SJ-554S |
| Carton Size: |
150 - ∞ (L) 160 - 500 (W)
100-500 (H) mm |
| Working Speed: |
700-1200 Carton/hrs |
| Tape Width: |
48mm, 72mm |
|
|
| |
| |
 |
| Pre-Stretch Pallet Wrapper |
| Model: |
SJ-4503 |
| Control system: |
PCB |
| Automatic height detecting |
| Turntable diameter: |
1500mm |
| Packing height: |
2100mm |
| Loading capacity: |
2000kg |
| Pre-stretch rate: |
300% |
| Max film reel inner diameter: |
75mm |
| Max film reel outer diameter: |
250mm |
| Turntable height: |
80mm |
| Power: |
240v 50Hz 1 phase |
|
|
| |
| |
 |
| Synthesi Pallet Wrapper |
| Features: |
| Control System: |
PCB |
| Folding Column: |
Simple and easily understood control panel
Front and rear forklift pick up points
Soft start and stop |
| Specification: |
| Power Supply 220V 50Hz 1Phase |
| Turntable diameter: |
1500 |
| Max wrapping height: |
2100mm |
| Turntable rotation speed: |
1-12rpm (adjustable) |
| Film carriage speed: |
1-90mm/sec (adjustable) |
| Max pallet weight: |
2000kg |
|
| |
- Mechanical brake film carriage
- Precise phase stopping at cycle and photocell sensing delay externally adjustable
- Manual control is available
- Machine specification is variable according to your requirement |
| |
| Options: |
| Power supply: |
110V or 380V |
| Ramp |
| Turntable diameter : |
1650mm, 1800mm, 2000mm |
| Pallet height: |
2400mm, 2650mm, 3000mm |
|
|
|
| |
| |
|
|
| |
|
